CERAMIC FIBER ROPES

UNIHEAT ROPE

UNIHEAT ROPE is a resilient ceramic fiber material used for a variety of high-temperature (1,260°C) gasketing, packing and sealing applications.
UNIHEAT ROPE PX 010 is superior quality packing braided from ceramic yarn reinforced with inconel wire. A dimension of 20 mm is made by overbraided technology. The product contains approximately 20% organic binders to facilitate the carding process. The binders burn at low temperatures, but without any effect on the special ceramic fibres. The packing is resistant to very high temperatures.


----------
Maximum Use Temperature:
1050 oC
Continuous Use Temperature:
1050 oC
Key Features:
- Low Thermal Conductivity
- Lightweigh
- Erosion resistance
- Contains No Asbestos
- Resistance to High Velocity
- High temperature stability


----------
Product properties
PX010
Temperature grade, oC
1260
Long Operation Temperature, oC
1050
Colour
White
Reinforces
Inconel
Section / cut
round / square
Chemical composition, %
- Al2O3
41-48
- SiO2
51-55
Diameter / Size
5 - 70 mm
download TDS
